3.5" SBC board, Intel J6412, DDR4, M.2 2242 SSD slot, 2 GbE, HDMI, DP, LVDS/eDP, 6 COM, 12-24V DC input
CPU on top side of the board.
Features
- Intel® Celeron J6412, Quad-core 2.0GHz (up to 2.6GHz), 10W TDP
- Up to 32GB DDR4 SO-DIMM memory
- Display outputs: DP 1.4, HDMI, LVDS, and eDP (triple display support)
- Dual GbE LAN with Realtek 8111H controllers
- 6 x COM, 4 x USB, 1 x 8-bit GPIO
- 1 x M.2 2242 B-Key SATA SSD, 1 x SATA 3.0
- M.2 2230 for Wi-Fi, M.2 3042 B-Key with SIM for 5G/4G
- 1 x Mini PCIe with SIM slot (PCIe/USB2.0)
- Phoenix terminal power input: 12–24V DC ±10%
- Supports TPM 2.0 (fTPM)
